1. The application of trailer chassis on drying and mixing hoist makes the structure simple and compact, simple and rapid seating, covering small space, transferring flexibly.
2. The intermittent drying cylinder and twin-shaft mixer tank integrated structural design ensures the thorough mixing, good quality of final products, stable performance, which meets the quality requirements of asphalt concrete for the high grade pavement.
3. The compact furnace equips with automatic ignition burner, which ensure high thermal efficiency.
4. The drying process is adjustable, which enable the aggregates with different water content can also reach the temperature standard, ensuring the quality standard of asphalt concrete.
5. The programmable logic controller (PLC) control is easy for testing, operation and centralized control, with high degree of automation, stable and reliable operation, simplifying the operation and improving production efficiency.
Technical Parameter
| Model | YLB-20 | YLB-30 | YLB-40 | YLB-60 | YLB-80 |
| Rated production capacity | 20 t/h | 30 t/h | 40 t/h | 60 t/h | 80 t/h |
| Power | 117 KW/139KW | 117 KW/139KW | 135KW/165KW | 171KW/222KW | 191 KW/251KW |
| Quantity of aggregate bin | 3 | 3 | 3 | 3 | 3 |
| Volume of cold aggregate bin | 6 | 6 | 6 | 6 | 6 |
| Loading width | 3.2m | 3.2m | 3.2m | 3.2m | 3.2m |
| Feeding height | Horizontal plane：2.5m | ||||
| Fuel and consumption | Light and heavy Oil≤ 6.5 kg / t; coal ≤ 14 kg / t | ||||
| Measurement Accuracy | Aggregate ± 0.5%; asphalt ± 0.2%; powder ± 0.3% | ||||
| Mixing tank capacity | 750kg | 1000kg | 1000kg | 1000kg | |
| Capacity of finished products bin | 9t | 9t | 9t | 9t | |
| Dust emission concentration | Cyclone dedust ≤750 mg/N；Water filter≤200 mg/N；Bag filter a50 mg/N | ||||
